In the program of screw compressors, you will now find EPM machines with power from 15 to 45 kW.
New range of SCR-EPM compressors was developed with regard to the most efficient production of compressed air in industrial plants, using the latest construction elements that provide its user with drastic reduction of financial costs associated with energy consumption.
SCR-EPM machines are equipped with robust airends providing a tremendous amount of air produced. Thanks to the direct connection of the airend with the electric motor, the compressors work without any energy losses in the transmission system.
Compressors with motors with permanent magnets and IE4 efficiency are additionally equipped as standard with a SCR9000 touchscreen electronic control unit with a 7" color display and, optionally, the connection of machine monitoring for data visualization and alarm messages via a mobile phone.
Basic description
- oil lubricated airend
- IE4 motor with permanent magnets
- speed control by frequency converter
- direct drive 1:1
- one-stage compressor
- SCR9000 electronic controller with 7" touch display
- ventilation with frequency converter
Pressure: 7, 8, 10 bar
FAD: 35-570 Nm3/h
